Repair
Rocker arms
3.5 Rocker arms
3.5.1 Rocker arms - Valve clearance set (SL 204)
Previous tasks
q Remove cylinder head covers. (For more information see: 3.4.3 Cylinder head cover removal
and installation, page 64.)
q Install turning device. (For more information see: 4.1.2 Turning device, page 261.)
Fig. 51: Turning device installed
Specific safety instructions
WARNING
Injuries by contact with hot surfaces!
Engine is hot near operating temperature. The contact with hot surfaces could lead serious
injuries or death.
u Avoid any contact with the engine, parts carrying hot coolant or oil, the exhaust system, the
turbocharger, the heat protection, the battery, the covers.
u After the temperature has cooled down to a level it can be touched, proceed with the tasks
on the engine.
68
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
