Repair
Electrical system
Specific values
Belt tension: 165 Hz (Min 149 Hz - Max 182 Hz).
Tightening specifications
Fig. 262: Belt tensioner
Reference
Key
Screw specifications
Lubricant *
Reuse**
Torque Angle (°)
Step
± 5%
Step
± 5°
1 441AD M10x55-10.9-Zinc Coating - Yes 1 50 Nm
37 ft-lb
- -
Tab. 49: Tightening specifications table
*Lubricants:
MG = Molykote G-n-plus
MW = Castrol Optimol paste white T
MH = Molykote HSC
O = Engine oil
XX = Loctite 243
YY = Loctite 577
**Refer to screws reuse rules. (For more information see: 5.3.2 Screws pre-tightening, reuse,
and marking, page 268.)
3.13.2 Starter removal and installation (SL 260)
Previous tasks
Not applicable.
240
© 2022 by Kohler Co. All rights reserved.
KD62V12 33525088601_8_1 EN_US
2022-09
