Repair
Cooling system
Specific safety instructions
NOTICE
Risk of property damage by reuse of sealing.
Leaks by faulty seal.
u Replace all sealings.
Special tools
Make sure that the following special tools are available:
– Guiding rod M12x230 – Thermostat (x2)
(For more information see: 4.1.1 Special tools, page 258.)
Consumables and equipment
Make sure that the following consumables and equipment are available:
– Vaseline
– Rags
– Cleaner
Overview
Fig. 237: Task overview
1
LT thermostat 5 Flange
2 Thermostat housing 6 Screw (M10)
3 Screw (M12) 7 O-ring
4 O-ring 8 Pipe
KD62V12 33525088601_8_1 EN_US
2022-09
© 2022 by Kohler Co. All rights reserved.
221
