8-8 82E-5 – 98E-5 SERIES
8. TURBOCHARGER
8.3.3 Waste gate valve adjustment procedure
Rotor play in radial direction
It is indispensable to adjust the waste gate valve opening pressure and lift after its overhaul or inner parts
replacement.
Negligence of this adjustment will adversely affect the engine performance.
[NOTICE]
If the adjustment is impossible, give up overhaul but replace the whole turbocharger assembly.
(1) Method for checking the waste gate valve opening pressure and lift
(a) Equipment
Prepare the equipment shown in the figure below.
