9. STARTING MOTOR
9.1 For 4D94LE/(S)4D98E
As a representative example of starting motor, the one for 4D94LE and (S)4D98E is shown in this chapter.
9.1.1 Specifications
Manufacturer's model (Hitachi) — S13-204 S13-205
Parts No. — YM129900-77010 YM129900-77020
Nominal output kW 2.3 2.3
Weight kg 5.5 5.5
Revolution direction (as viewed from pinion) — Clockwise Clockwise
Engagement system — Magnetic shift Magnetic shift
No-load
Terminal voltage/current V/A 11/140 or less 11/140 or less
Revolution rpm 4100 or above 4100 or above
Loaded
Terminal voltage/current V/A 2.5/1050 or less 2.5/1050 or less
Torque Nm {kgm} 24.5 {2.5} or above 24.5 {2.5} or above
Clutch system — Overrunning Overrunning
Pinion projection voltage (at 100°C) V 8.6 or less 8.6 or less
Pinion DP or module/number of teeth — M3/9 M3/9
Difference (O-ring, oil seal) — Dry (none) Wet (with)
Application — Standard Option
