INSTRUMENTS AND CONTROLS
3.3.2 WARNING LIGHTS
1 - GENERATOR WARNING LIGHT
RYA15480
h0000000
E
F
H
C
1 2 3 4
1 - Generator warning light
2 - Pre-heating warning light
3 - Engine oil pressure warning light
4 - Air cleaner clogging warning light
This warning light comes on and activates the acoustic alarm
when the starting circuit is energized and goes out when the en-
gine exceeds the idling speed; if this warning light remains on
even when the engine is running at the normal operating speed,
this means that the alternator does not work and the battery is not
charged correctly.
IMPORTANT
☞
• If the warning light remains off when the ignition key is
turned to position «I», this means that the alternator is
faulty or broken.
RWA07150
