77
FUSES AND RELAYS
3.4 FUSES AND RELAYS
3.4.1 CENTRAL UNIT FUSES AND RELAYS
IMPORTANT
• When changing a fuse, make sure that the ignition key is in position «».
• If the fuses are oxidized, corroded or do not fit perfectly in their seat, replace them only with new fuses
having the same capacity.
• If the engine does not run when the ignition switch is turned to position «» START, check the main
fuse and if necessary change it.
The fuses and relays are grouped on a single base positioned in-
side the seat support.
The central unit can be reached by opening the door (1).
RWAA1480
1
RWAA1520
