2-57
PC130/150LGP-6K ENG
12.OPERATION
12.4 MOVING MACHINE OFF
12.4.1 MOVING MACHINE FORWARD
• Before operating the travel levers, check the direction of the
track frame. If the sprocket is at the front, the operation of the
travel levers is reversed.
• When moving off, check that the area around the machine is
safe, and sound the horn before moving.
• Clear all personnel from the machine and the area.
• Clear all obstacles from the path of the machine.
• If the lever is moved inside the deceleration range, engine
speed will rise suddenly. Operate the levers carefully.
1. Set swing lock switch to the ON (actuated) position and conform
that swing lock monitor lamp lights up.
2. Turn fuel control dial towards the high idling position to increase
the engine speed.
3. Set safety lock lever in the FREE position, fold the work equip-
ment, and raise it 40 - 50 cm from the ground.
WARNING
