OPERATION OPERATION
3-95
ADJUSTING TRANSMISSION CUT-OFF POSITION 0.
CAUTION
Apply the parking brake before adjusting the transmission cut-off position.
In the transmission cut-off function, it is possible to adjust the depression position of the left brake pedal used to
shift the transmission to neutral.
1. Start the engine with starting switch (1), then set parking
brake switch (2) to the ON position.
2. Set transmission cut-off switch (3) to the ON position.
3. Depress left brake pedal (4) and set it to the desired posi-
tion to shift the transmission to neutral.
4. Press transmission cut-off set switch (5), then release it.
When the switch is released, the buzzer will sound with a
repeated short sound, and the cut-off position is set.
Method of canceling cut-off position
5. After the buzzer sounds in Step 4 of the adjustment proce-
dure, the transmission cut-off switch flashes for 2 seconds.
While it is flashing, press transmission cut-off set switch (5)
again and release it.
6. The buzzer will sound with a long sound and the adjusted
cut-off position is canceled.
STOPPING WHEN TRANSMISSION CUT-OFF IS ON 0.
When the transmission cut-off switch is at the ON position and the left brake pedal is depressed, the transmission
is shifted to neutral at the pre-selected brake pedal depression position.
The transmission is not shifted to neutral when the right brake pedal is operated.
REMARK
When the transmission cut-off switch is OFF, the left brake pedal acts in the same way as the right brake
pedal, and the transmission is not shifted to neutral.
