EXPLANATION OF COMPONENTS OPERATION
3-14
EMERGENCY STOP ITEM 0.
CAUTION
If these monitors light up and the buzzer sounds, stop operations immediately and carry out inspection
and maintenance of the applicable location.
If any abnormality is found in the emergency stop items, the alarm buzzer will sound intermittently, and the monitor
for the location of the abnormality and the central warning lamp will light up.
At the same time, “E03 CHECK RIGHT NOW“ is displayed on the character display, so stop the machine immedi-
ately in a safe place, stop the engine, and carry out inspection.
(1) Brake oil pressure caution lamp (3) Battery charge circuit caution lamp
(2) Engine oil pressure caution lamp (4) Steering oil pressure caution lamp
To Next Page
