HANDLING JOYSTICK STEERING SYSTEM ATTACHMENTS, OPTIONS
6-48
*: Does not shift up above speed range of gearshift lever.
OPERATION USING JOYSTICK LEVER AND OPERATION USING STEERING WHEEL
CAUTION
! If the directional lever and joystick FNR switch are not at the neutral position, the neutral interlock cir-
cuit makes it impossible to switch the transmission directional control (when the joystick ON/OFF
switch is ON, it is switched from the direc-
! tional lever to the joystick FNR switch; when the joystick ON/OFF switch is OFF, it is switched from
the joystick FNR switch to the directional lever).
! Do not use the joystick when traveling on public roads.
Select lever operation or steering wheel operation according to the work.
! Steering using joystick lever
This is suited for continuous loading operations on jobsites with ample space where the loading operation can
be carried out with a comparatively relaxed cycle time.
Because operations can be carried out with a small movements and light operating effort, this is also suitable
for reducing operator fatigue when operating continuously.
! Steering using steering wheel
This provides excellent fine control and ability to travel straight, so it is suitable for travel between jobsites and
for load and carry operations. In addition, it is also suitable for short cycle loading operations because it holds
the upper part of
the operator‘s body when frequently switching between FORWARD and REVERSE.
Selection Operation using joystick lever Operation using steering wheel
Joystick ON/OFF switch ON OFF
Steering
Steering using joystick lever (steering
with steering wheel is also possible)
Steering using steering wheel
Transmis-
sion
F/N/R
Operation using FNR switch at top of joy-
stick lever
Operation using transmission direc-
tional lever
Transmis-
sion type
Auto Auto
Shift mode
selector
switch
Manual Auto (L, M, H) Manual Auto (L, M, H)
Selection of
speed
range
Speed range selec-
tion using shift up,
shift down switches
at top of joystick
lever *
Automatic gear-
shifting according
to travel speed
Operation using
gearshift lever
Automatic gear-
shifting accord-
ing to travel
speed
