Krone EasyCut F 360 Original Operation Instructions

Maintenance
56
Pos: 24.52.10 / BA/Wartung/Mä hwerke/Messerschr aub / Mess erschnellverschlus s/Messersch nellverschluss H altebolzen 14mm @ 0\mod_1 197268087875_78 .docx @ 1644 4@ 33 @ 1
10.11.3 Blade Quick-Fit Device
Danger! - Insufficient thickness of material on the retaining bolts.
Effect: Danger to life or serious injuries.
• At every blade changing check the thickness of the holding bolts material.
• Damage or worn retaining bolts must always be replaced by sets on each cutting
disc/blade drum!
• The material thickness of the retaining bolts must not be less than 14 mm at the weakest
point.
• The material thickness of the leaf spring must not be less than 3 mm at the weakest
point.
EC-239-0
min. 14 mm
Fig. 31
Pos: 24.52.11 / BA/---------- -----Seitenumbruch---- ---------- -- @ 0\mod_1196175 311226_0.doc x @ 4165 @ @ 1
