MAINTENANCE WORK ON CHASSIS AND ENGINE 128
9.24Adjusting the footbrake pedal stub
700305-01
Remove the screw with the footbrake pedal stub.
Position the footbrake pedal stub with the screw in one of the holes according to the
desired lever length.
Guideline
Standard Central hole
Tighten screw.
Guideline
Screw, footbrake pedal stub M6 10 Nm
(7.4 lbf ft)
Loctite
®
243™
