CONTROLS 36

5.14Info display

400430-13

The info display  has two menus.

Menu 1 is ROAD mode (standard) for riding on public roads.

Menu 2 is RACE mode for riding on race courses. It allows riders to time laps themselves.

If the general warning lamp lights up, the corresponding message is shown periodically

in the info display.

Information repeat 45 s

The information shown in the info display can be controlled with the function buttons.
