MAINTENANCE WORK ON CHASSIS AND ENGINE 163

9.59Changing the fuses of individual power consumers

Warning

Fire hazard The electrical system can be overloaded by the use of incorrect fuses.

– Use only fuses with the prescribed amperage. Never by-pass or repair fuses.

Info

The fuse box containing the fuses of individual power consumers is located under the seat.

– Switch off all power-consuming components and switch off the engine.

– Remove the seat. ( p. 154)

700281-01

– Open fuse box cover .
