MAINTENANCE WORK ON CHASSIS AND ENGINE 176
700285-01
– Adjust the beam distance of the headlight by turning screw .
Guideline
The boundary between light and dark must be exactly on the lower mark for a motor-
cycle with a rider (mark is applied under: Checking headlight adjustment).
Info
Turn clockwise to increase the light range, turn counterclockwise to reduce the
light range.
If you have a payload, you may have to correct the headlight range.
9.65Activating/deactivating ignition key
Info
The orange programming key must only be used for activating and deactivating!
If a black ignition key is lost or replaced, the black ignition keys must be activated/deactivated using the orange programming key.
You can activate or deactivate up to four black ignition keys. Only the black ignition keys trained during an activation procedure are
valid. All black ignition keys not trained in the activation procedure are invalid, but can be retrained in a further activation proce-
dure.
700234-10
Loss of a black ignition key (second black ignition key available):
– Press the emergency OFF switch into the position .
– Insert the orange programming key in the ignition lock.
– Switch on the ignition by turning the orange programming key to the position .
EFI warning lamp (MIL) lights up, switches off, and then starts to flash.
The immobilizer indicator lamp lights up.
– Switch off the ignition by turning the orange programming key to the position .
– Pull out the orange programming key.
– Insert the black ignition key in the ignition lock.
