MAINTENANCE WORK ON CHASSIS AND ENGINE 145
700272-10
– Loosen screws and .
– Unscrew screw about 6 turns, press your hand on the screw to push the wheel spin-
dle out of the fork stub. Remove screw .
Warning
Danger of accidents Reduced braking effect caused by damaged brake discs.
– Always lay the wheel down in such a way that the brake discs are not dam-
aged.
– Holding the front wheel, withdraw the wheel spindle. Take the front wheel out of the
fork.
9.44Fitting front wheel x
200487-10
Warning
Danger of accidents Reduced braking due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with
brake cleaner when necessary.
– Clean screw and wheel spindle .
– Lift the front wheel into the fork, position it, and insert the wheel spindle.
– Mount and tighten screw .
Guideline
Screw, front wheel spindle M25x1.5 45 Nm
(33.2 lbf ft)
