MAINTENANCE WORK ON CHASSIS AND ENGINE 193
700364-01
– Position bushings .
– Mount and tighten screws .
Guideline
Remaining chassis screws M6 10 Nm (7.4 lbf ft)
– Fit the seat. ( p. 154)
9.77Checking engine oil level
Info
The engine oil level must be checked at normal engine operating temperature.
– Stand the motorcycle upright on a horizontal surface.
700301-10
– Remove oil dipstick . Check the engine oil level in the measurement range.
Info
After switching off the engine, wait one minute before checking the level.
The engine oil level must be in the middle of the measurement range of the oil
dipstick.
» If the engine oil level is outside the specified range:
– Top up the engine oil. ( p. 201)
– Replace the oil dipstick.
