TECHNICAL DATA - CHASSIS 226
Secondary drive 17:37
Chain 5/8 x 5/16” X‑ring
Steering head angle 66.7°
Wheelbase 1,435 mm (56.5 in)
Seat height, unloaded
Lower frame rear position 805 mm (31.69 in)
Upper frame rear position 825 mm (32.48 in)
Ground clearance, unloaded 110 mm (4.33 in)
Weight without fuel approx. 184 kg (406 lb.)
Maximum permissible front axle load 200 kg (441 lb.)
Maximum permissible rear axle load 220 kg (485 lb.)
Maximum permissible total weight 380 kg (838 lb.)
Battery YTZ14S Battery voltage: 12 V
Nominal capacity: 11 Ah
maintenance-free
Fuse 58011109130 30 A
Fuse 75011088015 15 A
Fuse 75011088010 10 A
18.1Lighting equipment
Low beam / high beam H7 12 V
55 W
Parking light W2,1x9,5d 12 V
5 W
Instrument lights and control lamps LED
