MAINTENANCE WORK ON CHASSIS AND ENGINE 184
700350-01
– Check the fluid level.
The fluid level must be between the MIN and MAX markings.
» If the fluid level does not meet specifications:
– Correct the fluid level of the hydraulic clutch. ( p. 184)
9.71Correcting fluid level of hydraulic clutch
Info
The fluid level rises with increasing wear of the clutch lining disc.
Do not use brake fluid.
– Move the clutch fluid reservoir mounted on the handlebar to a horizontal position.
700284-01
– Remove screw cover with membrane.
– Correct the fuel level.
Guideline
The fluid level must be between the MIN and MAX markings.
Hydraulic fluid (15) ( p. 236)
– Refit screw with membrane.
