MAINTENANCE WORK ON CHASSIS AND ENGINE 146
700271-12
– Position the brake calipers and check that the brake linings are seated correctly.
– Mount and tighten screws .
Guideline
Screw, front brake caliper M10x1.25 45 Nm
(33.2 lbf ft)
Loctite
®
243™
– Operate the hand brake lever several times until the brake pads are lying correctly on
the brake disc.
– Take the front of the motorcycle off the work stand. ( p. 103)
– Take the rear of the motorcycle off the work stand. ( p. 104)
700272-11
– Pull the front brake and compress the fork powerfully a few times.
The fork legs straighten.
– Fully tighten screws .
Guideline
Screw, fork stub M8 15 Nm
(11.1 lbf ft)
9.45Removing rear wheel x
– Jack up the motorcycle rear end. ( p. 104)
