KTM 500 EXC-F 2023 User Manual

23 TECHNICAL DATA
148
23.1 Engine
Design 1-cylinder 4-stroke engine, water-cooled
Displacement 510.9 cm³ (31.177 cu in)
Stroke 72 mm (2.83 in)
Bore 95 mm (3.74 in)
Compression ratio 12.75:1
Idle speed 1,800 … 1,900 rpm
Control OHC, 4 valves controlled via rocker arm
Valve diameter, intake 40 mm (1.57 in)
Valve diameter, exhaust 33 mm (1.3 in)
Valve clearance
Intake at: 20 °C (68 °F) 0.10 … 0.15 mm (0.0039 … 0.0059 in)
Exhaust at: 20 °C (68 °F) 0.12 … 0.17 mm (0.0047 … 0.0067 in)
Crankshaft bearing 2 cylinder roller bearing
Conrod bearing Slide bearing
Piston pin bearing No bearing bush – DLC coated piston pin
Pistons Forged light alloy
Piston rings 1 compression ring, 1 oil scraper ring
Engine lubrication Pressure circulation lubrication with 2 trochoidal
pumps
Primary transmission 31:76
Clutch Multidisc clutch in oil bath, hydraulically activated
Transmission ratio
first-gear 14:36
second-gear 17:32
third-gear 19:28
fourth-gear 22:26
fifth-gear 23:24
sixth-gear 26:21
Alternator 12 V, 196 W
Ignition Contactless controlled fully electronic ignition with
digital ignition adjustment
Spark plug NGK LZMAR8BI-10
Spark plug electrode gap 1.0 mm (0.039 in)
Cooling Water cooling, permanent circulation of coolant by
water pump
Starting aid Starter motor

KTM 500 EXC-F 2023 Specifications

General

Displacement	510.9 cm³
Bore x Stroke	95 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Clutch	Wet, DDS multi-disc clutch, Brembo hydraulics
Front Suspension	WP XPLOR-USD, Ø 48 mm
Weight (without fuel)	106.5 kg
Seat Height	960 mm
Ground Clearance	355 mm
ABS	No
Engine Type	Single Cylinder, 4-Stroke
Rear Suspension	WP XPLOR shock absorber
Front Brake	Disc brake
Rear Brake	Disc brake
Frame	Central double-cradle type 25CrMo4 steel
