13 SERVICE WORK ON THE CHASSIS

192

13.13 Installing the left side cover

F02033-10

Main work

–

Position the left side cover with holding lug

on bushing

and push backward.

The left side cover engages under the tail part.

–

Press the left side cover in area

into rubber bushing

and press into rubber bushing

in area

Finishing work

– Mount the seat. ( p. 180)
