CONTROLS 6

6.19 Seat lock

F02018-10

Seat lock

is located on the left side of the vehicle.

It can be unlocked using the ignition key.

6.20 Passenger foot pegs

F02019-10

The passenger foot pegs can be folded up and down.

Possible states

• Passenger foot pegs folded up – For operation without a pas-

senger.

• Passenger foot pegs folded down – For operation with a pas-

senger.
