TECHNICAL DATA 23

317

23.2 Engine tightening torques

Screw plug, water pump drain hole EJOTALtracs

Plus 60x14 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, bleeder flange EJOTALtracs

M6x12 8 Nm (5.9 lbf ft)

Loctite

243™

Hose clamp, intake flange M4 2.5 Nm (1.84 lbf ft)

Nozzle, engine vent M5 2 Nm (1.5 lbf ft)

Loctite

243™

Oil nozzle for piston cooling M5 2 Nm (1.5 lbf ft)

Loctite

243™

Oil nozzle in cylinder head M5 2 Nm (1.5 lbf ft)

Loctite

243™

Remaining screws, engine M5 6 Nm (4.4 lbf ft)

Screw, cam lever axial lock M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, gear position sensor M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, oil filter cover M5 6 Nm (4.4 lbf ft)

Screw, pressure plate M5 3 Nm (2.2 lbf ft)

Loctite

243™
