13 SERVICE WORK ON THE CHASSIS

200

13.19 Installing the left fuel tank spoiler

F02061-10

Main work

–

Position the left fuel tank spoiler with holding lug

on bush-

ing

and push backward laterally.

–

Press the fuel tank spoiler into rubber bushing

in area

Default Chapter5
