TECHNICAL DATA 23

327

23.6 Tires

Front tire Rear tire

90/90 - 21 M/C 54R M+S TL

Metzeler Karoo 3

150/70 - 18 M/C 70R M+S TL

Metzeler Karoo 3

The tires specified represent one of the possible series production tires. Additional information is available in

the Service section under:

http://www.ktm.com

23.7 Fork

Fork article number 14.18.8S.54

Fork WP SuspensionXPLOR 5548

Compression damping

Comfort 20 clicks

Standard 15 clicks

Sport 10 clicks

Full payload 15 clicks

Rebound damping

Comfort 18 clicks

Standard 15 clicks

Sport 10 clicks

Full payload 15 clicks
