CONTROLS 6
33
F02007-10
Overview of the left combination switch
1
Light switch ( p. 33)
2
Menu switch ( p. 37)
3
Turn signal switch ( p. 37)
4
Horn button ( p. 38)
6.4.2 Light switch
F01886-10
The light switch
1
is fitted on the combination switch on the
left.
Possible states
Low beam on – Light switch in position
A
. In this
position, the low beam and tail light are switched on.
High beam on – Push the light switch to position
B
.
In this position, the high beam and the tail light are
switched on.
Headlight flasher. – Push the light switch into posi-
tion
C
.
