9. FINAL REDUCTION
9-4
GRAND DINK 125/150
Inspect the final gear and final shaft for
wear, damage or seizure.
Check the left crankcase bearings for
excessive play and inspect the oil seal for
wear or damage.
Inspect the drive shaft and gear for wear or
damage.
Check the transmission case cover bearings
for excessive play and inspect the final
shaft bearing oil seal for wear or damage.
Drive Shaft Bearing
Final Shaft Bearing
Countershaft Bearing
Do not remove the transmission case
cover except for necessary part replace-
ment. When replacing the drive shaft,
also replace the bearing and oil seal.
＊
Drive Shaft Bearing
