GS14/GS16, Description of the System
17
2.2 System Concept
2.2.1 Software Concept
Description All instruments use the same software concept.
Software for all GS
GNSS instruments
Software upload
Uploading GS firmware can take some time. Ensure that the battery is at least
75% full before beginning the upload, and do not remove the battery during
the upload process.
2.2.2 Power Concept
General Use the batteries, chargers and accessories recommended by Leica Geosystems to
ensure the correct functionality of the instrument.
Power options Power for the instrument can be supplied either internally or externally. Up to two
external power supplies can be connected.
For permanent operations use Uninterruptible Power Supply units as a back-up in a
main power failure.
Software type Description
GS firmware
(GS_xx.fw)
This important software covers all functions of the instru-
ment.
The Web server application is integrated into the firmware
and cannot be deleted.
The English language is integrated into the firmware and
cannot be deleted.
Language software
(WEB_LANG.sxx)
Numerous languages are available for the Web server applica-
tion.
The English language is the default language. One language is
chosen as the active language.
Software for Description
All GS models The software can be uploaded using the Leica Web server
application or myWorld@Leica Geosystems.
Ensure that a Leica microSD card is inserted into the
GS instrument before starting the upload. Refer to
"4.3 Working with the Memory Device".
Internal power supply: One battery (GEB212) fits into the instrument.
External power supply: GEB371 battery connected via a cable.
OR
Car battery connected via a converter cable supplied
by Leica Geosystems.
OR
10.5 V-28 V DC power supply via a converter cable
supplied by Leica Geosystems.
OR
110 V/240 V AC to 12 V DC power supply unit,
supplied by Leica Geosystems.
