Leica GS16 User Manual

GS14/GS16, Operation
40
Connect to PC via
USB cable step-by-
step
4.1.6 Connecting to the Web Server
Description The Web server is a web-based tool to view the status of and configure the GNSS
instruments. The Web server application is integrated into the GS firmware and cannot
be deleted.
Accessing the Web
server via cable
step-by-step
Accessing the Web
server via Bluetooth
step-by-step
To access the Web server the tasks following have to be done:
• Configure the PC’s Bluetooth device
• Establish a Bluetooth connection between PC and GS
• Accessing the Web server
Configuring the PC’s Bluetooth device
Step Description
1. Start the PC.
2. Plug the cable into the instrument.
3. Turn on the instrument.
4. Plug the cable into the USB port of the PC.

Windows Device Manager cannot be used with
CS20/TS16/TS60/MS60.
5. Press the Windows Start button at the bottom left corner of the screen.
6. Type the IP address of the device into the search field.
• \\192.168.254.1\ for field controller
• \\192.168.254.3\ for other instruments
7. Press Enter.
A file browser opens. You can now browse within the folders on the instru-
ment.
Step Description
1. Start the PC and turn on the GS GNSS instrument.

Instead of connecting to your PC, you can connect your GS GNSS
instrument to the field controller.
2. Connect the GS GNSS instrument with the GEV234 cable to the PC. Refer to
"4.1.5 Connecting to a Personal Computer".
3. Double-Click the Configure GS connection shortcut from the desktop of
your PC. The GS GNSS network adapter is configured with IP address:
192.168.254.1. A DOS window appears when the configuration was
successful. Press any key to exit the DOS window. The Configure GS
connection shortcut disappears from the desktop.
4. Start the web browser of your PC.
5. Type in http://192.168.254.2 and press enter to access the web server of
GS instrument.
Step Description
1. Start your PC.
2. Activate the Bluetooth device of your PC.
3. Go StartSettingsNetwork Connections.
4. Double-click Bluetooth from the LAN or High-Speed Internet device list.
The Bluetooth Properties windows is started.

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
