GS14/GS16, User Interface
24
3.2 Operating Principles
Operating the
instrument
The GS14/GS16 GNSS instrument is operated either by the pressing its buttons
(ON/OFF button, function button) or by the field controller.
Operation by buttons
The GS14/GS16 GNSS instrument is operated by pressing its buttons. Refer to "3.1
Keyboard" for a detailed description of the buttons and their function.
Operation by field controller
The GS14/GS16 GNSS instrument is operated by the field controller using the Leica
SmartWorx Viva/Leica Captivate software. Refer to the User Manual of the field
controller for a detailed description of the keys and their function.
Turn on GS14/GS16 To turn on the instrument press and hold the Power button for 2 s.
Turn off GS14/GS16 To turn off the instrument:
• press and hold the ON/OFF button for 2 s
• confirm to power down the instrument when exiting the software on the field
controller

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
