GS14/GS16, Operation
32
4.1.3 Setting up as a Real-Time Rover
Use The equipment setup is used for real-time rover with extended periods of use in the
field.
Description Connections are made to the GNSS antenna, radio antenna and field controller.
The field controller is fixed to the pole with the GHT62. Connection between the
GS14/GS16 instrument and the field controller is made through Bluetooth.

• The antenna is mounted directly using screw fitting. If using stub and adapter,
procedures can vary slightly.
• When using the pole with stub, ensure that the antenna and the screw-to-stub
adapter slide down the full length of the stub before tightening the locking ring. An
incorrectly mounted antenna will have a direct effect on the results.
• Aluminium poles are used. They can be replaced with their carbon fibre equivalent
without any change to these instructions.
• Standard radio is used throughout the instructions. Digital cellular phones can also
be used but the setup can differ slightly.

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
