Leica GS16 User Manual

GS14/GS16, Description of the System
19
2.3 Container Contents
Container for GS
instrument and
accessories 1/2
a) GHT63 clamp
b) Manuals and USB documentation card
c) GEB212 or GEB311 batteries
d) Antenna
e) GAT18 mobile antenna
f) GAT21, GAT25 or GAT26 radio antenna
g) Tribrach
h) CS15 field controller with GHT62_only holder or CS20 field controller with GHT66
holder or CS35 tablet
i) Height hook
j) Cables
k) GDC221 car adapter
l) SD cards
m) Stylus
n) GAD34 arm 3 cm
o) TNC QN-adapter
p) Allen key and adjustment tool
009340_001
a
b
c
i
j
l
m
k
d
d
e
f
g
h
n
o
p

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
