GS14/GS16, Operation
28
4.1.2 Setting up as a Real-Time Base
Use The equipment setup described is used for real-time base stations with the need of
optimal radio coverage. Raw observation data can also be collected for post-
processing.
Description The GS14/GS16 instrument can be programmed with the field controller before use
which can then be omitted from the setup.
The connection between GS14/GS16 and the field controller is made via Bluetooth.
The radio antenna is mounted on the antenna arm which clips to the GNSS antenna.
• The antenna is mounted directly using screw fitting. If using stub and adapter,
procedures can vary slightly.
• When using the adapter and carrier, ensure that the antenna and the adapter
assembly slide down the full length of the carrier stub. An incorrectly mounted
antenna will have a direct effect on the results.
• Standard radio is used throughout the instructions. Digital cellular phones can also
be used but the setup can differ slightly.
If the instrument is left in the container during use in high temperatures, the lid should
be left open. Refer to the User Manual for operating and storage temperatures.
Use an external battery such as GEB371 to ensure operation for a full day.
