Leica GS16 User Manual

GS14/GS16, Technical Data
49
6Technical Data
6.1 GS14/GS16 Technical Data
6.1.1 Tracking Characteristics GS14
Satellite reception Dual frequency
Supported signals

Carrier phase and code measurements on L1 and L2 are fully independent with AS on
or off.
6.1.2 Tracking Characteristics GS16
Satellite reception Multi-frequency
Instrument
channels

Depending on the satellite systems and signals configured, a maximum number
of 555 channels is allocated.
Supported signals

Carrier phase and code measurements on L1, L2 and L5 (GPS) are fully independent
with AS on or off.

Support of QZSS L1, L2S, L5Q, L6L and IRNSS L5A is incorporated and will be provided
through future firmware upgrade.
System Signal
GPS L1 C/A, L2P, L2C
GLONASS L1 C/A, L2P, L2C
Galileo E1, E5b
BeiDou B1, B2
System Signal
GPS L1 C/A, L2P, L2C, L5
GLONASS L1 C/A, L2P, L2C
Galileo E1, E5a, E5b, AltBOC
BeiDou B1, B2

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
