GS14/GS16, Description of the System
21
2.4 Instrument Components

The instrument can be preprogrammed using the Web server application running from
the instrument on a web browser of a Windows device. Connect the instrument to a
computer using a cable. Turn on the instrument by holding down the Power key for
2 s. A green blinking light at both power LEDs indicates that the instrument powers up.
GS14/GS16
components

A Bluetooth port is included inside all GS GNSS instruments to enable connectivity to
the field controller.
a) QN-connector for external UHF
antenna, only for models with UHF
radio
b) Battery compartment with microSD
and SIM card slot
c) LEDs, ON/OFF button and Function
button
d) LEMO port, serial and USB
e) Mechanical Reference Plane (MRP)
004107_002
a
b
c
d
e

Leica GS16 Specifications

General

Channels	555
GNSS Supported	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Operating Temperature	-40°C to +65°C
Battery Life	Up to 10 hours
RTK Accuracy (Horizontal)	8 mm + 1 ppm
RTK Accuracy (Vertical)	15 mm + 1 ppm
Dust and Water Protection	IP68
Static Accuracy (Horizontal)	3 mm + 0.5 ppm
Static Accuracy (Vertical)	5 mm + 0.5 ppm
Data Logging Rate	20 Hz
Communication	Bluetooth
