Figure 6. Remove the memory modules

Go to https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following

replacement part:

Memory modules

Remove the left SSD bracket

Make sure the following FRUs (or CRUs) have been removed.

“Remove the lower case” on page 28

Step 1. Disconnect the battery pack cable from the system board. Remove three screws and then remove

the left SSD bracket.

Attention: Use your fingernail to pull the connector to unplug it. Do not pull the cable.

Figure 7. Remove the left SSD bracket

Chapter 4. Removing a FRU or CRU 31
