Lenovo Legion Pro 5 16IRX8 User Manual

Figure 35. Remove two screws and then remove the camera bracket
Screw specifications
Number of screws
M1.6 × L2.5 2
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Camera bracket
Remove the LCD panel
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the LCD unit” on page 49
“Remove the hinge cover” on page 52
“Remove the LCD bezel” on page 52
“Remove the camera bracket” on page 53
Step 1. Pull out the removable tapes. Then, lift the LCD panel.
54
Lenovo Legion Pro 5i (16″, 8) and Lenovo Legion Pro 5 (16″, 8) Hardware Maintenance Manual

Lenovo Legion Pro 5 16IRX8 Specifications

General

Battery	80Wh
Wireless	Wi-Fi 6E, Bluetooth 5.1
Processor	Up to Intel Core i9-13900HX
Graphics	NVIDIA GeForce RTX 4070
Display	16" WQXGA (2560x1600)
RAM	Up to 32GB DDR5
Operating System	Windows 11 Pro
Weight	2.5 kg
Audio	2 x 2W Harman Speakers, Nahimic Audio
Ports	3x USB-A, 1x HDMI 2.1, 1x RJ45, 1x 3.5mm audio jack
