Lenovo Legion Pro 5 16IRX8 User Manual

Figure 20. Remove the USB board
Screw specifications
Number of screws
M2 × L3.5 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
USB board
Remove the battery pack
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the left SSD bracket” on page 31
Step 1. Remove six screws and then remove the battery pack.
42
Lenovo Legion Pro 5i (16″, 8) and Lenovo Legion Pro 5 (16″, 8) Hardware Maintenance Manual

Lenovo Legion Pro 5 16IRX8 Specifications

General

Battery	80Wh
Wireless	Wi-Fi 6E, Bluetooth 5.1
Processor	Up to Intel Core i9-13900HX
Graphics	NVIDIA GeForce RTX 4070
Display	16" WQXGA (2560x1600)
RAM	Up to 32GB DDR5
Operating System	Windows 11 Pro
Weight	2.5 kg
Audio	2 x 2W Harman Speakers, Nahimic Audio
Ports	3x USB-A, 1x HDMI 2.1, 1x RJ45, 1x 3.5mm audio jack
