Figure 18. Remove the Wi-Fi card
Screw specifications
Number of screws
M2 × L1.8 1
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Wi-Fi card
Remove the thermal module
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the left SSD bracket” on page 31
“Remove the right SSD bracket” on page 35
Step 1. Disconnect the thermal module connectors from the system board. Loosen seven screws in
alphabetical order and remove four screws. Then, remove the thermal module.
40
Lenovo Legion Pro 5i (16″, 8) and Lenovo Legion Pro 5 (16″, 8) Hardware Maintenance Manual

Lenovo Legion Pro 5 16IRX8 Specifications

General

Battery	80Wh
Wireless	Wi-Fi 6E, Bluetooth 5.1
Processor	Up to Intel Core i9-13900HX
Graphics	NVIDIA GeForce RTX 4070
Display	16" WQXGA (2560x1600)
RAM	Up to 32GB DDR5
Operating System	Windows 11 Pro
Weight	2.5 kg
Audio	2 x 2W Harman Speakers, Nahimic Audio
Ports	3x USB-A, 1x HDMI 2.1, 1x RJ45, 1x 3.5mm audio jack
