Lenovo Legion Pro 5 16IRX8 User Manual

Chapter 5. Label locations
Figure 43. Label layout on the back side of the base cover
Labels attached to the base cover are country/region specific. Make sure to apply the appropriate labels to
the replacement base cover.
Table 5. All base cover labels
Label Label description Applied country/region Label dimensions
1
Rating label All 66 mm x 24 mm
2
Rating print label All 43 mm x 24 mm
3
OS label All 16 mm x 22.5 mm
4
CO2 offset label All 18 mm x 18 mm
5
Country label
Korea 50 mm x 16 mm
Taiwan 70 mm x 10 mm
Indonesia 26 mm x 10 mm
Vietnam 10 mm x 9 mm
Argentina 68 mm x 6 mm
Malaysia 8 mm x 8mm
India (BIS)
22 mm x 30 mm
6
WL/BT label
Brazil 16.5 mm x 15 mm
Taiwan 32 mm x 10 mm
Israel 32 mm x 10 mm
South Africa
20 mm x 10 mm
Argentina 32 mm x 10 mm
© Copyright Lenovo 2023 61

Lenovo Legion Pro 5 16IRX8 Specifications

General

Battery	80Wh
Wireless	Wi-Fi 6E, Bluetooth 5.1
Processor	Up to Intel Core i9-13900HX
Graphics	NVIDIA GeForce RTX 4070
Display	16" WQXGA (2560x1600)
RAM	Up to 32GB DDR5
Operating System	Windows 11 Pro
Weight	2.5 kg
Audio	2 x 2W Harman Speakers, Nahimic Audio
Ports	3x USB-A, 1x HDMI 2.1, 1x RJ45, 1x 3.5mm audio jack
