Figure 21. Remove the battery pack
Screw specifications
Number of screws
M2 × L5 6
Go to
https://support.lenovo.com/partslookup to look up the Lenovo part numbers of the following
replacement part:
Battery pack
Remove the touchpad cable
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 28
“Remove the left SSD bracket” on page 31
“Remove the battery pack” on page 42
Step 1. Disconnect the touchpad cable from the touchpad board and the system board, and then remove
the touchpad cable.
Chapter 4. Removing a FRU or CRU 43

Lenovo Legion Pro 5 16IRX8 Specifications

General

Battery	80Wh
Wireless	Wi-Fi 6E, Bluetooth 5.1
Processor	Up to Intel Core i9-13900HX
Graphics	NVIDIA GeForce RTX 4070
Display	16" WQXGA (2560x1600)
RAM	Up to 32GB DDR5
Operating System	Windows 11 Pro
Weight	2.5 kg
Audio	2 x 2W Harman Speakers, Nahimic Audio
Ports	3x USB-A, 1x HDMI 2.1, 1x RJ45, 1x 3.5mm audio jack
