8.EnsurethatthescrewholesinthenewThinkServerRAIDSuperCapacitorModulewiththebracket
arealignedwiththecorrespondingstubsinthechassis.Then,installthescrewtosecurethenew
ThinkServerRAIDSuperCapacitorModulewiththebracketinplace.
Figure126.InstallingtheThinkServerRAIDSuperCapacitorModulewiththebracketonthechassis
9.ConnectthecabletothenewThinkServerRAIDSuperCapacitorModule.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacementprocedure,goto“Completingthepartsreplacement”onpage180.
ReplacingtheAnyRAIDadapter
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Readthisfirst:safety
information”onpageiii
and“Guidelines”onpage69.
ThistopicappliesonlytoservermodelsthathaveanAnyRAIDadapterinstalled.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourserverortheAnyRAIDadaptermightlookdifferentfromtheillustrationsin
thistopic.
•UseanydocumentationthatcomeswiththeAnyRAIDadapterandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToreplacetheAnyRAIDadapter,dothefollowing:
Attention:ReplacingtheAnyRAIDadaptermightimpactyourRAIDconfigurations.Backupyourdata
beforeyoubegintoavoidanydatalossduetoaRAIDconfigurationchange.
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
Chapter6.Replacinghardware159
