7 Drive application
7.3 Setting parameters (short overview)
138
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Output words Name Assignment
Word 1 DriveControlStatus Status word
• For bit assignment, see table below.
Word 2 MotorSpeedAct Actual speed value
• Scaling: 16384 ≡ 100 % reference speed (C011
)
Word 3 MotorSpeedSet Resulting overall setpoint
• Scaling: 16384 ≡ 100 % reference speed (C011
)
Word 4 - Not preconfigured
Status word Name Status
Bit 0 FreeStatusBit0 Free status bit 0 (configurable in C621/7
)
Not assigned in Lenze setting.
Bit 1 PowerDisabled 1 ≡ Inverter control inhibited (pulse inhibit is active)
Bit 2 FreeStatusBit2 Free status bit 2 (configurable in C621/8
)
In Lenze setting pre-assigned with LA_NCtrl_bImaxActive signal:
1 ≡ The current setpoint is internally limited (the controller ope-
rates at the maximum current limit)
Bit 3 FreeStatusBit3 Free status bit 3 (configurable in C621/9
)
In the Lenze setting pre-assigned with
LA_NCtrl_bSpeedSetReached signal:
1 ≡ Speed setpoint reached
Bit 4 FreeStatusBit4 Free status bit 4 (configurable in C621/10
)
In the Lenze setting pre-assigned with LA_NCtrl_bSpeedActEqSet
signal:
1 ≡ Actual speed value has reached the setpoint within one hys-
teresis band
Bit 5 FreeStatusBit5 Free status bit 5 (configurable in C621/11
)
In the Lenze setting pre-assigned with LA_NCtrl_bNActCompare
signal:
• In case of "open loop" operation:
1 ≡ speed setpoint < comparison value (C024
)
• In case of "open loop" operation
1 ≡ actual speed value < comparison value (C024
)
Bit 6 ActSpeedIsZero 1 ≡ current speed is 0
Bit 7 ControllerInhibit 1 ≡ Controller inhibited (controller inhibit is active)
Bit 8 StatusCodeBit0 Bit coded display of the active device state
Device states
(see table [4-1])
Bit 9 StatusCodeBit1
Bit 10 StatusCodeBit2
Bit 11 StatusCodeBit3
Bit 12 Warning 1 ≡ A warning exists.
Bit 13 Trouble 1 ≡ Controller is in the "Trouble
" device state
•E.g. if an overvoltage has occurred.
Bit 14 FreeStatusBit14 Free status bit 14 (configurable in C621/12
)
In the Lenze setting pre-assigned with LA_NCtrl_bSpeedCcw sig-
nal:
0 ≡ Clockwise direction of rotation (Cw), 1 ≡ Counter-clockwise
direction of rotation (Ccw)
Bit 15 FreeStatusBit15 Free status bit 15 (configurable in C621/13
)
In Lenze setting pre-assigned with LA_NCtrl_bDriveReady signal:
1 ≡ Drive controller is ready for operation
