Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 298
10 Parameter reference
10.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.2.1 Selection lists for configuration parameters
10.2.1.1 Selection list - analog signals
This selection list is relevant for the following
parameters:
Parameter
C00620 16-bit system connection
C00700
LA_NCtrl: Analog connection list
Selection list - analog signals
0 Not connected
1 C_nPos100_a(100.0%)
2 C_nNeg100_a(-100.0%)
3 C_nPos199_9_a(199.9%)
4 C_nNeg199_9_a(-199.9%)
5 C_w65535
6C_wDriveCtrl
10 AIn1_Out
20 nPar1_a
21 nPar2_a
22 nPar3_a
23 nPar4_a
24 LS_Keypad_nTorqueMotLim_a
25 LS_Keypad_nTorqueGenLim_a
26 LS_Keypad_nMainSetValue_a
30 CAN1_wIn1
31 CAN1_wIn2
32 CAN1_wIn3
33 CAN1_wIn4
34 CAN2_wIn1
35 CAN2_wIn2
36 CAN2_wIn3
37 CAN2_wIn4
50 LA_NCtrl_nMotorFreqAct_a
51 LA_NCtrl_nMotorSpeedSet_a
52 LA_NCtrl_nMotorSpeedAct_a
53 LA_NCtrl_nMotor Voltage_a
54 LA_NCtrl_nDCVoltage_a
55 LA_NCtrl_nMotorCurrent_a
56 LA_NCtrl_nMotorTorqueAct_a
57 LA_NCtrl_nHeatsinktemperature_a
58 LA_NCtrl_nOutputSpeedCtrl_a
70 LA_NCtrl_wDeviceStateWord
71 LA_NCtrl_wDeviceAuxStateWord
72 LA_NCtrl_wDetermFailNoLow
73 LA_NCtrl_wDetermFailNoHigh
