10 Parameter reference
10.2 Parameter list | C00136
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00136
Parameter | Name:
C00136 | Communication control words
Data type: UNSIGNED_16
Index: 24439
d
= 5F77
h
Control words of the communication interfaces
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 SwitchOn
Bit 1 IMP
Bit 2 SetQuickStop
Bit 3 EnableOperation
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 ResetFault
Bit 8 SetHalt
Bit 9 reserved_1
Bit 10 reserved_2
Bit 11 LenzeSpecific_1
Bit 12 LenzeSpecific_2
Bit 13 LenzeSpecific_3
Bit 14 SetFail
Bit 15 LenzeSpecific_4
Subcodes Info
C00136/1 Reserved
C00136/2 CAN control word
• Control word of the communication interface CAN
(CAN on board)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
