10 Parameter reference
10.2 Parameter list | C00727
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00727
C00728
C00729
C00800
C00801
Parameter | Name:
C00727 | LS_Keypad: Digital values
Data type: UNSIGNED_8
Index: 23848
d
= 5D28
h
Executing control commands when operating via keypad
Setting range (min. value | unit | max. value)
01
Subcodes Lenze setting Info
C00727/1 0 "1" ≡ request quick stop
C00727/2 0 "1" ≡ request DC-injection braking
C00727/3 0 "1" ≡ request change of direction of rotation
C00727/4 0 "1" ≡ request fixed speed setpoint 1
C00727/5 0 "1" ≡ request fixed speed setpoint 2
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00728 | LS_Keypad: Keypad analog values
Data type: INTEGER_16
Index: 23847
d
= 5D27
h
Selection of different setpoints when operating via keypad
Setting range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Lenze setting Info
C00728/1 100.0 % Torque limit in motor mode
C00728/2 100.0 % Torque limit in generator mode
C00728/3 0.0 % Setpoint speed
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00729 | Keypad/PC: Speed setpoint
Data type: INTEGER_16
Index: 23846
d
= 5D26
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00800 | L_MPot_1: Upper limit
Data type: INTEGER_16
Index: 23775
d
= 5CDF
h
FB L_MPot_1: Upper limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 100.0 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00801 | L_MPot_1: Lower limit
Data type: INTEGER_16
Index: 23774
d
= 5CDE
h
FB L_MPot_1: Lower limit of the motor potentiometer function
Setting range (min. value | unit | max. value) Lenze setting
-199.9 % 199.9 -100.0 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
