10 Parameter reference
10.2 Parameter list | C00806
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00806
C00830
C00831
Parameter | Name:
C00806 | L_MPot_1: Use
Data type: UNSIGNED_8
Index: 23769
d
= 5CD9
h
FB L_MPot_1: Use of the motor potentiometer
Selection list (Lenze setting printed in bold) Info
0No The motor potentiometer is not used.
• The analog value applied to the nIn_a input is looped
through without any changes to the nOut_a output.
1 Yes The motor potentiometer is used.
• The analog value applied at the nIn_a input is led via
the motor potentiometer and provided at the nOut_a
output.
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00830 | 16-bit analogue input
Data type: INTEGER_16
Index: 23745
d
= 5CC1
h
Display in percent of 16-bit input values of different blocks
Display range (min. value | unit | max. value)
-199.9 % 199.9
Subcodes Info
C00830/1 L_NSet_1
: nNSet_a
C00830/2 L_NSet_1
: nOut_a
C00830/3 LS_MCTRL: nSpeedSetValue_a
C00830/4 LS_MCTRL: nTorqueMotLimit_a
C00830/5 LS_MCTRL: nTorqueGenLimit_a
C00830/6 L_PCTRL_1
: nAct_a
C00830/7 L_PCTRL_1
: nAdapt_a
C00830/8 L_PCTRL_1: nSet_a
C00830/9 L_PCTRL_1
: nInflu_a
C00830/10 L_PCTRL_1: nNSet_a
C00830/11 L_MPot_1
: nIn_a
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00831 | 16-bit common input
Data type: UNSIGNED_16
Index: 23744
d
= 5CC0
h
Decimal/hexadecimal/bit-coded display of 16-bit input values of different blocks
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Bit0
... ...
Bit 15 Bit15
Subcodes Info
C00831/1 LS_DCTRL
: wCANControl
Read access Write access CINH PLC STOP No transfer COM MOT
To Next Page
