Lenze 8400 BaseLine C User Manual

10 Parameter reference
10.2 Parameter list | C00868
295
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00868
C00909
Parameter | Name:
C00868 | CAN output words
Data type: UNSIGNED_16
Index: 23707
d
= 5C9B
h
Display of the 16-bit output values of the CAN interface
System bus "CAN on board"
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Bit0
Bit 1 Bit1
Bit 2 Bit2
Bit 3 Bit3
Bit 4 Bit4
Bit 5 Bit5
Bit 6 Bit6
Bit 7 Bit7
Bit 8 Bit8
Bit 9 Bit9
Bit 10 Bit10
Bit 11 Bit11
Bit 12 Bit12
Bit 13 Bit13
Bit 14 Bit14
Bit 15 Bit15
Subcodes Info
C00868/1 LP_CanOut1
: wOut1
C00868/2 LP_CanOut1
: wOut2
C00868/3 LP_CanOut1: wOut3
C00868/4 LP_CanOut1
: wOut4
C00868/5 LP_CanOut2
: wOut1
C00868/6 LP_CanOut2: wOut2
C00868/7 LP_CanOut2
: wOut3
C00868/8 LP_CanOut2
: wOut4
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Maximum positive/negative speed for all operating modes
Setting range (min. value | unit | max. value)
0.0 % 175.0
Subcodes Lenze setting Info
C00909/1 120.0 % Max. pos. speed
C00909/2 120.0 % Max. neg. speed
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
